UBERTI 1862 Police Perkusní revolver

UBERTI 1862 Police Perkusní revolver

Rozkres perkusního revolveru výrobce A.UBERTI model 1862 Police.

c1



N. Code No. Q.ty Description
1 A0070001 1 POLICE62 FRAME ASSEMBLY
2 A0070002 1 POLICE62 HAMMER ASSEMBLY
3 0071003 1 BARREL 5.1/2″ .36
4 0070004 1 WEDGE
5 A0070005 1 POLICE62 .36 CYLINDER ASSEMBLY
7 A0070007 1 POLICE62 HAND ASSEMBLY
8 0070008 1 BACKSTRAP
9 0070009 1 BARREL STUD
10 0070010 1 TRIGGER
11 0070011 1 GRIP
12 0070012 1 BOLT
13 A0071013 1 POLICE62 5.1/2″ LOADING LEVER ASSEMBLY
15 0070015 1 SIGHT
19 0070019 1 TRIGGER BOLT SPRING
20 0070020 1 MAIN SPRING
24 0070024 1 PLUNGER
26 0070026 1 TRIGGERGUARD
28 0070028 1 CYLINDER LOCK PIN
31 0070031 1 FRONT TRIGGERGUARD SCREW
32 0000032 3 REAR BACKSTRAP SCREW
32 0070032 2 REAR BACKSTRAP SCREW
33 0070033 1 WEDGE SCREW
34 0070034 1 PLUNGER SCREW
35 0070035 1 SCREW
36 0000036 1 MAIN SPRING SCREW
37 0070037 1 HAMMER SCREW
38 0070038 1 TRIGGER SCREW
40 0070040 1 BOLT SCREW
